Mean Well NPB-240-24TB Battery Charger 240W 24V Terminal Block
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NPB-240-24TB Battery Charger 240W 24V Terminal Block
Description
Description
Specifications
Specifications
-
BrandMean Well
-
SeriesNPB Series
-
Power Rating240 Watt
-
Output Voltage28.8 Volt
-
Rated Current8 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.09 in
-
Width3.78 in
-
Height1.93 in
-
Weight2.87 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well NPB-240-24TB used for?
The NPB-240-24TB is an AC-DC battery charger and power supply designed for 24V-class applications. This model provides up to 240W of output and is suited to commercial or industrial environments where a regulated 28.8Vdc output at up to 8A is required.
What are the main output specifications of the NPB-240-24TB?
This model is rated for 240W output power with a nominal output of 28.8Vdc. Its rated output current is 8A, making it appropriate for applications that need a higher-power 24V battery charging solution.
Does the NPB-240-24TB support multi-stage battery charging?
Yes. The product description specifies 2-stage or 3-stage charging capability, which is useful for buyers comparing chargers based on charging profile support. That makes this model more application-specific than a basic fixed-output power supply.
Can this charger operate in demanding temperature conditions?
The NPB-240-24TB has a specified operating temperature range from -30°C to 70°C. That wide range makes it a practical option for industrial environments where ambient conditions can vary significantly.
What kind of AC input does the NPB-240-24TB accept?
This model is specified with universal AC input. For B2B buyers, that means it is intended for use across a wide range of standard AC supply environments without requiring a region-specific input version.
How heavy is the Mean Well NPB-240-24TB, and what warranty does it include?
The unit weight is 1.3 kg. Mean Well specifies this model with a 3-year warranty, which is relevant for buyers evaluating lifecycle cost and long-term equipment support.
