Mean Well RDDW20G-05 DC-DC Converter - 20W - 18~75V in ±5V out
miniature size, economical, withstand 5G vibration and 70°C operation, dual output
SKU:
RDDW20G-05
$38.12 USD
Unit price /
Unavailable
Shipping calculated at checkout.
|
Notify me when it's back in stock
Your order will be processed within 24 hours
Description
Description
Features
Compliance with EN50155 railway standard |
DIP 2" x 1" package with standard pinout |
4:1 wide input range |
Wide operating temperature range -40~+85°C |
No minimum load required |
Fully encapsulated |
Protections: Short circuit(Continuous)/Overload/Over voltage/Input under voltage |
1.5KVDC, 3KVDC I/O isolation by models |
Remote ON/OFF control |
3 years warranty |
General Specification
Voltage Accuracy | ±1.5% |
Overload Protection | 110~160% rated output power |
Efficiency | 90% |
Short circuit protection | Continuous, automatic recovery |
Working temperature | -40°C to +85°C |
EMC | Compliance to EN55032 class A, EN61000-4-2,3,4,5,6 |
Temp. Coefficient | 0.03% / ℃ (0 ~ 71℃) |
Dimension (LxWxH) (mm) | 50.8*25.4*10.2mm |
Potting material | Non-conductive black plastic |
Specifications
Specifications
-
BrandMean Well
-
SeriesRSD Series
-
Power Rating20 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage18V~75V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,EMC,RCM
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.4 in
-
Weight0.08 lb
