Mean Well HVG-480-36AB Power Supply 480W 36V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HVG-480-36AB Power Supply 480W 36V - Adjustable and Dimmable
The HVG-480 is a 480W Mean Well power converter (input range: 180~528VAC).
Key Features
- ✓ Input voltage range: 180~528VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750 (type”HL”), CSA C22.2 No. 250.13-12, IP65 or IP67, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVG Series
-
Power Rating478.8 Watt
-
Output Voltage36 Volt
-
Rated Current13.3 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length10.32 in
-
Width4.92 in
-
Height1.72 in
-
Weight6.17 lb
::specification::
Frequently Asked Questions
Can I use the HVG-480-36AB for 36V LED lighting that needs dimming control?
Yes, as long as the 36V LED load stays within 478.8W and 13.3A. This version is designed for 36V lighting applications where adjustable and dimmable operation is needed.
Is the HVG-480-36AB suitable for 36V illuminated signage?
It can be used for 36V illuminated signage if the connected load fits the 18-36V CC range and does not exceed 478.8W. That makes it suitable for larger sign lighting assemblies using 36V LED loads.
Can this driver work in commercial buildings with higher AC input voltage?
Yes. Its 180-528VAC input range allows it to operate across a wide range of commercial AC supply conditions for lighting and signage systems.
What is the difference between the HVG-480-36A, HVG-480-36AB, and HVG-480-36B?
All three 36V versions are rated 478.8W with 13.3A output. The HVG-480-36A is adjustable, the HVG-480-36AB is adjustable and dimmable, and the HVG-480-36B is dimmable; the A and AB versions are IP65 Water-Resistant, while the B version is IP67 Waterproof.
How much 36V LED strip can the HVG-480-36AB handle?
The driver's maximum output is 478.8W. To estimate strip length, divide 478.8W by your strip's rated watts per meter, and check your strip rated power per meter before sizing.
Is the HVG-480-36AB meant for wet or outdoor conditions?
It has an IP65 Water-Resistant rating, so it is suited to outdoor or damp-use lighting where the driver is protected from harsher water exposure. Its operating temperature range is -40°C to +85°C.
