Mean Well HVG-480-24A Power Supply | 480W 24V - Adjustable

Name: Mean Well HVG-480-24A Power Supply 480W 24V - Adjustable 20A
Brand: Mean Well
SKU: HVG-480-24A
Price: 170.06 USD
Availability: InStock

Overview

HVG-480-24A is the 24V output model of this series: rated current 20A, rated power 480W, typical efficiency 94%.

HVG-480 series is a 480W AC/DC LED driver featuring the dual mode constant voltage and constant current output. HVG-480 operates from 180~528VAC and offers models with different rated voltage ranging between 24V and 54V. Thanks to the high efficiency up to 95%, with the fanless design, the entire series is able to operate for -40℃~+85℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HVG-480 is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Wide input range 180 ~ 528VAC
Constant Voltage + Constant Current mode output
Metal housing with ClassⅠdesign
Built-in active PFC function
IP67 / IP65 rating for indoor or outdoor installations
Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off) ; Smart timer dimming
Typical lifetime>50000 hours
5 years warranty

Specifications

HVG-480-24ASpecifications from the official datasheet (2018-09-30 edition)Download datasheet PDF

OUTPUT

DC VOLTAGE: 24V
CONSTANT CURRENT REGION^Note.4: 12 ~ 24V
RATED CURRENT: 20A
RATED POWER: 480W
RIPPLE & NOISE (max.)^Note.2: 200mVp-p
VOLTAGE ADJ. RANGE: Adjustable for A/AB-Type only (via built-in potentiometer) 20.4 ~ 25.2V
CURRENT ADJ. RANGE: Adjustable for A/AB-Type only (via built-in potentiometer) 10 ~ 20A
VOLTAGE TOLERANCE^Note.3: ±1.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME^Note.6: 500ms, 100ms / 230VAC, 347VAC, 480VAC
HOLD UP TIME (Typ.): 16ms / 347VAC, 480VAC

INPUT

VOLTAGE RANGE^Note.5: 180 ~ 528VAC 254VDC ~ 747VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.98/230VAC, PF≧0.98/277VAC, PF≧0.97/347VAC, PF≧0.95/480VAC @ full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20% (@ load≧50% at 230VAC/277VAC/347VAC/480VAC input Please refer to “TOTAL HARMONIC DISTORTION (THD)” section
EFFICIENCY (Typ.): 94%
AC CURRENT (Typ.): 1.52A / 347VAC 1.15A / 480VAC
INRUSH CURRENT(Typ.): COLD START 40A(twidth=1100μs measured at 50% Ipeak) at 480VAC ; Per NEMA 410
MAX. NO. of PSUs on 16A CIRCUIT BREAKER: 4unit(circuit breaker of type B) / 6units(circuit breaker of type C) at 480VAC
LEAKAGE CURRENT: <0.75mA / 480VAC

PROTECTION

OVER CURRENT: 95 ~ 108% Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 26 ~ 30V Shut down output voltage, re-power on to recovery
OVER TEMPERATURE: Shut down output voltage, re-power on to recovery

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +85℃(Please refer to "OUTPUT LOAD vs TEMPERATURE" section)
MAX. CASE TEMP.: Tcase=+85℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 60℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750 (type”HL”), CSA C22.2 No. 250.13-12, IP65 or IP67, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to FCC Part 15 Subpart B, EAC TP TC 020
EMC IMMUNITY: Immunity Line-Earth 4KV, Line-Line 2KV, EAC TP TC 020

OTHERS

MTBF: 318.9K hrs min. Telcordia SR-332(Bellcore) ; 84.5K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 262*125*43.8mm (L*W*H)
PACKING: 2.8Kg;4pcs/12.2Kg/0.55CUFT

Test conditions and notes11

1. All parameters NOT specially mentioned are measured at 347VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Please refer to "DRIVING METHODS OF LED MODULE".
5. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.
7. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
8. This series meets the typical life expectancy of >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 80℃ or less.
9. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
10. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
11. For any application note and IP water proof function installation caution, please refer our user manual before using.

Technical drawings

HVG-480-24A BLOCK DIAGRAM — BLOCK DIAGRAM

HVG-480-24A DIMMING OPERATION — DIMMING OPERATION

HVG-480-24A H V G - 4 8 0 series — H V G - 4 8 0 series

HVG-480-24A OUTPUT LOAD vs TEMPERATURE(Note.9) — OUTPUT LOAD vs TEMPERATURE(Note.9)

HVG-480-24A STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

HVG-480-24A TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

HVG-480-24A MECHANICAL SPECIFICATION — MECHANICAL SPECIFICATION

Typical applications

LED greenhouse lighting
LED statium lighting
LED mining lighting
Type “HL” for use in Class I, Division 2 hazardous (Classified) location

Downloads

Datasheet1

HVG-480-24A datasheethvg_480_spec.pdf · 2018-09-30 edition PDF Download

Certificates3

Mean Well HVG-480-FCC Certificate PDF Download

Mean Well IDLC Series UL Certificate PDF Download

Mean Well IDLC Series EAC Certificate PDF Download

Test reports1

Mean Well HVG-480-24 Test Report PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the HVG-480-24A for long 24V LED strip runs in commercial signage?

Yes, it is sized for 24V signage or lighting loads up to 480W total. With a 24V output and 20A output current, it fits higher-power 24V strip lighting as long as the full connected load stays within 480W.

Is this driver suitable for 24V architectural or cove lighting projects?

It can be used for 24V architectural lighting where the total fixture load does not exceed 480W. The 24V output makes it appropriate for 24V lighting products, and the IP65 water-resistant housing helps where the driver may be exposed to dust or moisture.

Can this power supply run multiple 24V LED lighting sections from one driver?

It can support larger 24V lighting loads because it provides up to 480W and 20A. That makes it a fit for multi-section 24V lighting systems when the combined rated load remains at or below 480W.

How much 24V LED strip can the HVG-480-24A power?

Use the strip's rated power per meter and divide 480W by that number to estimate the maximum length. The math is: maximum strip length = 480W / strip watts per meter, and you should also make sure the strip is a 24V product and that the total load does not exceed 20A.

Is the HVG-480-24A okay for outdoor or wet-location lighting?

This model is rated IP65 water-resistant, so it is intended for environments where protection from water exposure and dust is needed. If your project needs a waterproof version in this power and voltage class, the sibling HVG-480-24B is the IP67 model.
