Mean Well HVG-480-36AB Power Supply 480W 36V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HVG-480-36AB Power Supply 480W 36V - Adjustable and Dimmable
Description
Description
Features
| 180~528VAC wide input range |
| Constant Voltage + Constant Current mode output |
| Metal housing with Class I design |
| Built-in active PFC |
| IP67 / IP65 rating for indoor or outdoor installations |
| Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off) ; Smart timer dimming |
| Typical lifetime>50000 hours |
| 5 years warranty |
General Specification
| AC input voltage range | 180~528VAC (single phase); 254~747VDC |
| AC inrush current (max.) | COLD START 40A(twidth=1100 s measured at 50% I μ peak) at 480VAC; Per NEMA 410 |
| DC adjustment range | ±10% rated output voltage |
| Current adjustment range | 55%~100% |
| Over current protection | 95%~108% constant current limiting, auto-recovery |
| Over-voltage protection | 110%~140% rated output voltage |
| Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature | -40~+85ºC (refer to output derating curve) |
| Safety standards | UL8750 (type”HL”), CSA C22.2 No. 250.13-12, IP65 or IP67, EAC TP TC 004 approved |
| EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, FCC part 15 class B |
| Connection Input | UL rated, STW 18AWGx3C (30cm) |
| Connection Output A&D-Type | SJTW 14AWGx2C (30cm) |
| Connection Output B-Type | SJTW 14AWGx2C (30cm) + UL2517 18AWGx2C (30cm) |
| Dimension (LxWxH) (mm) | 262 x 1258x 43.8 |
Specifications
Specifications
-
BrandMean Well
-
SeriesHVG Series
-
Power Rating478.8 Watt
-
Output Voltage36 Volt
-
Rated Current13.3 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length10.32 in
-
Width4.92 in
-
Height1.72 in
-
Weight6.17 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the HVG-480-36AB for 36V LED lighting that needs dimming control?
Yes, as long as the 36V LED load stays within 478.8W and 13.3A. This version is designed for 36V lighting applications where adjustable and dimmable operation is needed.
Is the HVG-480-36AB suitable for 36V illuminated signage?
It can be used for 36V illuminated signage if the connected load fits the 18-36V CC range and does not exceed 478.8W. That makes it suitable for larger sign lighting assemblies using 36V LED loads.
Can this driver work in commercial buildings with higher AC input voltage?
Yes. Its 180-528VAC input range allows it to operate across a wide range of commercial AC supply conditions for lighting and signage systems.
What is the difference between the HVG-480-36A, HVG-480-36AB, and HVG-480-36B?
All three 36V versions are rated 478.8W with 13.3A output. The HVG-480-36A is adjustable, the HVG-480-36AB is adjustable and dimmable, and the HVG-480-36B is dimmable; the A and AB versions are IP65 Water-Resistant, while the B version is IP67 Waterproof.
How much 36V LED strip can the HVG-480-36AB handle?
The driver's maximum output is 478.8W. To estimate strip length, divide 478.8W by your strip's rated watts per meter, and check your strip rated power per meter before sizing.
Is the HVG-480-36AB meant for wet or outdoor conditions?
It has an IP65 Water-Resistant rating, so it is suited to outdoor or damp-use lighting where the driver is protected from harsher water exposure. Its operating temperature range is -40°C to +85°C.
