SKM30W8-12

Name: SKM30W8-12
Brand: Mean Well
SKU: SKM30W8-12
Price: 30.17 USD
Availability: InStock

SKU:

SKM30W8-12

$30.17 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The SKM30W8-12 is a 30W single output DC-DC converter in a compact 2"×1" SIP package, delivering 12V at 2.50A. With an 89% typical efficiency and a wide 4:1 input voltage range (9–36V or 18–75V depending on input), it is suitable for industrial, telecom, and battery-powered applications.

Key Features

✓30W output power, single output
✓Output: 12V at 2.50A
✓8:1 ultra-wide input voltage range
✓89% typical efficiency
✓3000VDC (3kV) isolation voltage
✓Compact 2"×1" SIP package (50.8×25.4×13.7mm)
✓Operating temperature: −40°C to +85°C
✓Short circuit, over voltage, over current protection
