Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out 600mA
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage5 Volt
-
Rated Current0.6 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.87 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SLC03C-05 for a 5V logic rail in industrial controls with a higher input range?
Yes, this model is designed for constant-voltage 5V output applications up to 3W. It accepts 36-75VAC input and provides 5V output with a listed 600A output current, which fits low-power 5V logic or controller circuits within that input window.
Is the SLC03C-05 a good fit for embedded electronics on equipment that runs in the 36-75VAC range?
It is suited to low-power embedded electronics that need a regulated 5V rail from a 36-75VAC source. The compact 21.1 × 13.8 × 8.55 mm package and 0.0045 kg weight also support dense designs.
Can this converter power a small 5V monitoring or communication module in automation equipment?
Yes, if the module requires constant 5V output and stays within the converter's 3W rating. The 36-75VAC input range makes it relevant where a higher-voltage AC supply is already present in the system.
Is the SLC03C-05 suitable for indoor or outdoor use?
The operating temperature range is -40°C to +85°C, so it can handle a broad range of environmental temperatures. No IP rating is provided in the specs, so outdoor exposure should not be assumed without a separate protective enclosure.
What is the difference between the SLC03C-05 and the other SLC03C versions?
The SLC03C series shares the same 3W platform and 36-75VAC input range, but the outputs differ. The SLC03C-05 is 5V with a listed 600A output current, the SLC03C-12 is 12V with 250A, and the SLC03C-15 is 15V with 200A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out 600mA | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out 600mA | 3W | 5V | 0.6A | Indoor | $9.76 | View |
