Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out
Description
Description
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SLC03B-15 to power a 15V control circuit in industrial equipment?
Yes, this converter is intended for constant-voltage 15V output applications up to 3W. It accepts 18-36VAC input and provides 15V output with a listed 200A output current, which makes it suitable for low-power 15V control or signal circuits within that input range.
Is the SLC03B-15 suitable for embedded 15V electronics inside a compact system?
It can fit space-constrained embedded designs because the body is 21.1 × 13.8 × 8.55 mm and weighs 0.0045 kg. The unit is a 3W constant-voltage converter, so it is best matched to low-power 15V electronics rather than higher-load subsystems.
Can this DC-DC converter be used in automation panels that have 18-36VAC available?
Yes, if the panel provides 18-36VAC and the load needs a regulated 15V constant-voltage output within the converter's 3W rating. Its compact size also helps where board or enclosure space is limited.
Is the SLC03B-15 appropriate for harsh temperature environments?
It is rated for operation from -40°C to +85°C, so it covers a wide temperature range for industrial and embedded environments. No IP rating is listed, so outdoor or washdown use should not be assumed from the provided specs alone.
How does the SLC03B-15 compare with the other SLC03B models?
All three SLC03B models are 3W DC-DC converters in the same series. The SLC03B-05 provides 5V output with a listed 600A output current, the SLC03B-12 provides 12V with 250A, and the SLC03B-15 provides 15V with 200A.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
