Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out 600mA
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage5 Volt
-
Rated Current0.6 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SLC03B-05 to derive 5V power inside higher-voltage control equipment?
This model provides constant voltage 5V output with a 3W rating and accepts 18-36VAC input. That makes it suitable for low-power 5V electronics in systems that operate within the 18-36VAC input range.
Is the SLC03B-05 suitable for compact embedded control boards in industrial devices?
It is a compact converter at 21.1 × 13.8 × 8.55 mm and 0.0045 kg, which supports use in dense embedded assemblies. The output is 5V constant voltage and the power rating is 3W for low-power board-level circuits.
Can this converter support 5V monitoring or logic circuits in automation enclosures?
Yes, it is aligned with low-power 5V monitoring or logic circuits that need regulated constant voltage output. The source side must stay within the 18-36VAC input range, and the load must stay within the 3W rating.
Is the SLC03B-05 suitable for very cold or very warm operating conditions?
The operating temperature range is -40°C to +85°C, so it is specified for a wide thermal range. The provided data does not include an IP rating, so ingress protection is not defined here.
Can the SLC03B-05 be used outdoors?
The temperature range of -40°C to +85°C is listed, but no IP rating is provided. Since environmental sealing is not specified, outdoor suitability cannot be confirmed from these specs alone.
How does the SLC03B-05 differ from the other SLC03B models?
The SLC03B-05 is rated at 3W with 5V output and 600A output current. The SLC03B-12 is 3W with 12V output and 250A output current, and the SLC03B-15 is 3W with 15V output and 200A output current. All three share the same 18-36VAC input range.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out 600mA | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out 200mA | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out 250mA | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out 600mA | 3W | 5V | 0.6A | Indoor | $9.76 | View |
