Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out
Description
Description
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SLC03C-12 for a 12V industrial control or sensing circuit?
Yes, it is built for constant-voltage 12V output applications up to 3W. With a 36-75VAC input range and a listed 250A output current, it fits low-power 12V control, sensing, or interface circuits within those limits.
Is the SLC03C-12 appropriate for embedded 12V subsystems in compact equipment?
It is a compact option for low-power 12V embedded subsystems because the package measures 21.1 × 13.8 × 8.55 mm and weighs 0.0045 kg. The constant-voltage output is intended for regulated 12V loads rather than variable-output use.
Can this model be used where 36-75VAC is already available in an automation cabinet?
Yes, provided the load requires 12V constant-voltage output and remains within the 3W rating. That makes it relevant for small automation modules that need 12V from a higher AC input range.
How well does the SLC03C-12 handle temperature extremes?
The specified operating range is -40°C to +85°C, which is broad for industrial and embedded environments. Since no IP rating is listed, the temperature range alone does not make it an outdoor-rated product.
How does the SLC03C-12 differ from the 5V and 15V versions in the same series?
All SLC03C models are 3W converters with 36-75VAC input, but they provide different outputs. The SLC03C-05 is 5V with a listed 600A output current, the SLC03C-12 is 12V with 250A, and the SLC03C-15 is 15V with 200A.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
