Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out
Description
Description
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage9V~18V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SLC03A-12 for 12V industrial control electronics?
This converter is intended for constant voltage 12V output at 3W, which fits low-power industrial control electronics that require regulated 12V. Its input range is 9-18VAC, so the source needs to stay within that window.
Is the SLC03A-12 a fit for embedded 12V interface boards in automation equipment?
It is a compact option for embedded 12V interface or support boards because it measures 21.1 × 13.8 × 8.55 mm and weighs 0.0045 kg. The output is constant voltage 12V with a 3W rating for low-power board-level use.
Can this model support small 12V monitoring or signaling circuits?
Yes, it is aligned with small 12V monitoring or signaling circuits that need constant voltage output rather than higher-power conversion. The key limits are its 12V output and 3W power rating.
Would the SLC03A-12 work in equipment exposed to wide temperature swings?
The rated operating temperature span is -40°C to +85°C, so it is designed for wide temperature variation. That covers the thermal range in the spec sheet, but the listed data does not provide an IP rating.
Can I use the SLC03A-12 outdoors?
The temperature specification is -40°C to +85°C, but outdoor suitability cannot be confirmed from temperature alone. No IP rating is listed, so the product's protection against dust or water is not defined in these specs.
What is the difference between the SLC03A-12 and the other SLC03A variants?
The SLC03A-12 is rated for 3W, 12V output, and 250A output current. In the same series, the SLC03A-05 is 3W with 5V output and 600A output current, while the SLC03A-15 is 3W with 15V output and 200A output current. All share the same 9-18VAC input range.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
