Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out
Description
Description
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SLC03B-12 for 12V control or automation subcircuits?
This converter delivers constant voltage 12V output at 3W, which fits low-power control or automation subcircuits needing regulated 12V. Its specified input range is 18-36VAC.
Is the SLC03B-12 a good fit for embedded 12V electronics in compact industrial equipment?
It is designed for compact assemblies, with dimensions of 21.1 × 13.8 × 8.55 mm and a weight of 0.0045 kg. The unit provides 12V constant voltage output and is rated for 3W.
Can this model be used for small 12V interface or signaling modules?
It can be used for low-power 12V interface or signaling modules where constant voltage output is required. The application needs to stay within the 3W rating and use an 18-36VAC input source.
Does the SLC03B-12 support operation across a wide temperature range?
Yes. The listed operating temperature range is -40°C to +85°C, so it is specified for broad temperature variation. The specs shown do not include an IP rating.
Is the SLC03B-12 suitable for outdoor use?
The available environmental data includes a -40°C to +85°C operating range, but no IP rating is listed. Without a stated IP rating, the product's resistance to dust or water exposure is not defined in the provided specs.
What are the main differences between the SLC03B-12 and its siblings?
The SLC03B-12 is 3W with 12V output and 250A output current. In the same series, the SLC03B-05 is 3W with 5V output and 600A output current, while the SLC03B-15 is 3W with 15V output and 200A output current. All use the same 18-36VAC input range.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out | 3W | 15V | 0.2A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
