Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SLC03A-15 DC-DC Converter - 3W - 9~18V in 15V out
Description
Description
3 years warranty
Key Features
- ✓DIP16 package with industry-standard pinout
- ✓Operating temperature range -40~+85°C
- ✓2:1 wide input range
- ✓No minimum load required
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓High efficiency up to 82%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓1.5KVDC I/O isolation
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSLC Series
-
Power Rating3 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage9V~18V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.83 in
-
Width0.54 in
-
Height0.34 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SLC03A-15 for low-power 15V automation electronics?
This model is a constant voltage 15V DC-DC converter rated at 3W, so it fits low-power automation electronics that require regulated 15V output. Its input range is 9-18VAC.
Is the SLC03A-15 suitable for compact embedded 15V circuits?
It is designed for space-constrained electronics, with dimensions of 21.1 × 13.8 × 8.55 mm and a weight of 0.0045 kg. The converter provides 15V constant voltage output with a 3W rating for small embedded circuits.
Can this converter be used for 15V signal-conditioning or interface modules?
It can suit low-power 15V signal-conditioning or interface modules where a constant voltage output is required. The main limits are the 15V output level and the 3W power rating.
Does the SLC03A-15 handle demanding temperature conditions?
The specified operating temperature range is -40°C to +85°C, which supports use across demanding thermal conditions. The environmental data provided does not include an IP rating, so sealing performance is not stated.
Is the SLC03A-15 intended for outdoor environments?
The listed operating temperature range is -40°C to +85°C, but the spec set does not state any IP rating. Without an IP rating, outdoor exposure suitability is not established from the provided information.
How does the SLC03A-15 compare with the other SLC03A converters?
The SLC03A-15 is rated at 3W with 15V output and 200A output current. The SLC03A-05 is 3W with 5V output and 600A output current, and the SLC03A-12 is 3W with 12V output and 250A output current. All three use a 9-18VAC input range.
Other SLC03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SLC03C-15 DC-DC Converter - 3W - 36~75V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03C-12 DC-DC Converter - 3W - 36~75V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03C-05 DC-DC Converter - 3W - 36~75V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03B-15 DC-DC Converter - 3W - 18~36V in 15V out | 3W | 15V | 0.2A | Indoor | $9.13 | View |
| Mean Well SLC03B-12 DC-DC Converter - 3W - 18~36V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03B-05 DC-DC Converter - 3W - 18~36V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
| Mean Well SLC03A-12 DC-DC Converter - 3W - 9~18V in 12V out | 3W | 12V | 0.25A | Indoor | $9.76 | View |
| Mean Well SLC03A-05 DC-DC Converter - 3W - 9~18V in 5V out | 3W | 5V | 0.6A | Indoor | $9.76 | View |
