Mean Well DCWN06A-15 DC-DC Converter - 6W 9~18V DC in 15V out
The DCWN06A is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage9V~18V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
What is the DCWN06A-15 typically used for?
The Mean Well DCWN06A-15 is typically used as a compact isolated DC-DC converter for generating a regulated 15V output from a 9-18V DC input. With 6W rated power and 0.2A output current, it is intended for low-power 15V auxiliary and control applications.
Is the DCWN06A-15 a good fit for low-power 15V circuits from a 12V-class DC input?
Yes. The DCWN06A-15 converts a 9-18V DC input into a regulated 15V output at up to 0.2A, making it suitable for low-power isolated 15V rails when the application stays within the unit's 6W capability.
Why choose the DCWN06A-15 over a 3W 15V DCWN converter?
The key benefit is greater output headroom. At 6W, the DCWN06A-15 can support a larger 15V load than 3W models such as the DCWN03A-15 or DCWN03E-15, while keeping the same compact isolated module format.
Can the DCWN06A-15 operate across wide temperatures?
Yes. The published working temperature range is -40°C to +90°C, allowing use in a broad range of industrial and embedded environments when the converter is used within specification.
How does the DCWN06A-15 compare with the other 06A models?
The DCWN06A-15 is the 15V output variant of the 6W 06A family, while the DCWN06A-05 and DCWN06A-12 provide 5V and 12V outputs from the same 9-18V input range. Selection mainly depends on the output voltage your low-power circuit needs.
