Mean Well DCWN06B-05 DC-DC Converter - 6W 18~36V DC in 5V out
The DCWN06B is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage5 Volt
-
Rated Current0.5 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
What is the DCWN06B-05 typically used for?
The Mean Well DCWN06B-05 is typically used as a compact isolated DC-DC converter for stepping an 18-36V DC input down to a regulated 5V output. With 6W rated power and 0.5A output current, it is well suited to low-power 5V electronics in 24V-class DC systems.
Is the DCWN06B-05 a good fit for 24V-class DC systems that need a 5V rail?
Yes. The DCWN06B-05 is designed for an 18-36V input range and provides a 5V output at up to 0.5A, which makes it a practical fit for low-power 5V circuits fed from 24V-class DC sources.
What makes the DCWN06B-05 useful in isolated embedded designs?
The DCWN06B-05 combines a DIP24 package, no minimum load requirement, and 3KVDC I/O isolation with 6W output capacity. That combination makes it useful for isolated low-power designs where compact size and output margin both matter.
Can the DCWN06B-05 operate in industrial temperature ranges?
Yes. The published operating temperature range is -40°C to +90°C, supporting use in a wide range of industrial environments when the system stays within the converter's rated limits.
How does the DCWN06B-05 compare with related DCWN models?
The DCWN06B-05 is the 5V output version in the 6W 06B group, while the DCWN06B-12 and DCWN06B-15 provide 12V and 15V outputs from the same 18-36V input class. Compared with 3W DCWN03B models, the main difference is the higher output power capacity.
