Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well DCWN06B-15 DC-DC Converter - 6W 18~36V DC in 15V out
Description
Description
The DCWN06B is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the DCWN06B-15 typically used for?
The Mean Well DCWN06B-15 is typically used as a compact isolated DC-DC converter for generating a regulated 15V output from an 18-36V DC input. With 6W rated power and 0.2A output current, it is intended for low-power 15V auxiliary and control applications in 24V-class DC systems.
Is the DCWN06B-15 a good fit for low-power 15V rails from a 24V-class DC source?
Yes. The DCWN06B-15 converts an 18-36V DC input into a 15V output at up to 0.2A, making it suitable for low-power isolated 15V circuits that fit within its 6W rating.
What features make the DCWN06B-15 useful in compact isolated systems?
The DCWN06B-15 offers a DIP24 package, 3KVDC isolation, no minimum load requirement, and typical efficiency up to 87%. Those characteristics make it useful in compact low-power industrial and embedded designs.
Can the DCWN06B-15 be used in demanding temperature environments?
Yes. Its published operating temperature range is -40°C to +90°C, which supports use in a broad range of industrial conditions when the converter is used within specification.
How does the DCWN06B-15 compare with nearby DCWN models?
The DCWN06B-15 is the 15V output member of the 6W 06B group, while the DCWN06B-05 and DCWN06B-12 provide 5V and 12V outputs from the same 18-36V input class. Compared with 3W DCWN03B models, the main distinction is the higher 6W output capacity.
