Mean Well DCWN06C-15 DC-DC Converter - 6W 36~72V DC in 15V out
The DCWN06C is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
Can I use the DCWN06C-15 to power a 15V industrial control or instrumentation circuit?
This model is intended for constant-voltage 15V output when the input source is within the 36-72V DC range. It can deliver up to 0.2A with a 6W rating, so it fits low-power control or instrumentation circuits that stay within those limits.
Is the DCWN06C-15 suitable for a compact 15V embedded module inside factory equipment?
It is a practical option for compact embedded 15V electronics that need conversion from a higher-voltage DC bus. The 31.8 x 20.3 x 10.2 mm package and 0.0125 kg weight are useful where enclosure space is limited.
Can this 15V converter support low-power analog or interface sections in automation equipment?
It can support low-power 15V analog or interface sections if the total demand stays within 0.2A and 6W. Because it is a constant-voltage converter, it is intended for electronics that require a regulated 15V rail rather than higher-current loads.
Is the DCWN06C-15 suitable for outdoor panels or exposed environments?
The operating temperature range is -40C to +90C, which supports use across a wide temperature span. However, no IP rating is listed in the provided specs, so exposed outdoor use cannot be confirmed from the product data alone.
How does the DCWN06C-15 compare with the 5V and 12V versions?
All three models in the series are rated at 6W and have the same 31.8 x 20.3 x 10.2 mm dimensions, 0.0125 kg weight, and -40C to +90C operating temperature range. The DCWN06C-15 provides 15V at 0.2A, while the DCWN06C-12 provides 12V at 0.25A and the DCWN06C-05 provides 5V at 0.5A.
