Mean Well DCWN06C-12 DC-DC Converter - 6W 36~72V DC in 12V out
Description
Description
The DCWN06C is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DCWN06C-12 for a 12V automation device on a 36-72V DC system?
Yes, this converter is designed for constant-voltage 12V output from a 36-72V DC input source. It provides up to 0.25A with a 6W rating, so it fits low-power automation devices that stay within those output limits.
Is the DCWN06C-12 appropriate for powering a small 12V embedded subsystem inside industrial equipment?
It is appropriate for compact 12V embedded subsystems that need regulated output from a higher-voltage DC bus. With dimensions of 31.8 x 20.3 x 10.2 mm and a weight of 0.0125 kg, it is suited to space-constrained equipment designs.
Can this converter be used for 12V signal-conditioning or monitoring modules?
It can be used for 12V signal-conditioning or monitoring modules if the total load does not exceed 0.25A and 6W. The constant-voltage 12V output makes it better suited to stable low-power electronics than to variable or higher-demand loads.
Can the DCWN06C-12 work in equipment exposed to very low or very high temperatures?
The specified operating temperature range is -40C to +90C, so it is designed for broad temperature conditions in industrial environments. That temperature capability helps when the converter is used inside equipment that sees cold starts or elevated internal heat.
What is the difference between the DCWN06C-12 and the other models in the same series?
The DCWN06C-12 shares the same 6W rating, 31.8 x 20.3 x 10.2 mm dimensions, 0.0125 kg weight, and -40C to +90C operating temperature range as the other DCWN06C versions. The difference is the output: this model is 12V at 0.25A, while the DCWN06C-05 is 5V at 0.5A and the DCWN06C-15 is 15V at 0.2A.
