Mean Well SBTN01M-15 DC-DC Converter - 1W 12V DC in 15V out
The SBTN01M is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSBTN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.51 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the SBTN01M-15 for a low-power 15V industrial control signal circuit?
It can fit low-power 15V control or signal applications where the load stays within 1W and 0.07A. The listed operating mode is constant voltage, so it is intended for circuits that require a regulated 15V output.
Is this converter suitable for embedded electronics that need a small 15V auxiliary rail?
Yes, it is sized for very small embedded or automation subcircuits that need 15V at up to 0.07A. Its 12.9 x 10.9 x 7.1 mm body and 0.0011 kg weight make it appropriate where board space and mass are limited.
Can the SBTN01M-15 support a 15V analog or sensing stage in industrial equipment?
It is appropriate for a low-current 15V analog, measurement, or sensing stage if the total demand does not exceed 0.07A or 1W. The input range is listed as 10-13VAC, so it should be matched to systems in that input window.
How does the SBTN01M-15 compare with the other SBTN01M models?
All listed SBTN01M models are 1W converters in the same family. The sibling outputs are 5V at 0.2A for SBTN01M-05, 9V at 0.11A for SBTN01M-09, 12V at 0.08A for SBTN01M-12, and 15V at 0.07A for SBTN01M-15.
Is the SBTN01M-15 suited for harsh temperature environments or outdoor use?
The specified operating temperature is -40C to +90C, which supports use across a wide temperature range. No IP rating is listed in the provided specs, so the product data does not establish outdoor or washdown suitability.
