Mean Well DLW05C-15 DC-DC Converter - 5W - 36~72V in ±15V out
Description
Description
The DLW05C is a 5W Mean Well power converter.
Key Features
- ✓ 1KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDLW Series
-
Power Rating5 Watt
-
Output Voltage15 Volt
-
Rated Current0.16 Ampere
-
Input Voltage36V~72V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~71°C
-
Warranty2 Year
-
Length2 in
-
Width1 in
-
Height0.44 in
-
Weight0.07 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DLW05C-15 in a high-voltage control system that needs a 15V rail?
This converter is intended for 36-72VAC input and provides constant-voltage 15V output at 5W. It is a fit for low-power control, interface, or analog sections that need 15V from a source in that higher input range.
Is the DLW05C-15 suitable for instrumentation or signal-conditioning electronics that require 15V?
Yes, it can suit instrumentation or signal-conditioning circuits that need a regulated 15V rail, provided the available input is 36-72VAC. The 5W rating means it is intended for modest-power electronics rather than larger 15V loads.
Can this model be used in compact embedded systems with limited board space?
The package measures 50.8 × 25.4 × 11.27 mm and weighs 0.032 kg, so it is built for compact layouts. That makes it practical for embedded assemblies that need 15V conversion without using a larger power module.
Is the DLW05C-15 appropriate for outdoor equipment enclosures?
The specified operating range is -25°C to +71°C, which supports a wide temperature span. No IP rating is listed in the specs, so the product data does not identify it as weather-resistant or outdoor-rated.
What are the output options in the DLW05C family?
The listed DLW05C siblings all use 36-72VAC input and 5W power. Output choices are 5V with 500A for the DLW05C-05, 12V with 208A for the DLW05C-12, and 15V with 167A for the DLW05C-15.
Other DLW05 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well DLW05C-12 DC-DC Converter - 5W - 36~72V in ±12V out | 5W | 12V | 0.20A | Indoor | $14.95 | View |
| Mean Well DLW05C-05 DC-DC Converter - 5W - 36~72V in ±5V out | 5W | 5V | 0.5A | Indoor | $14.95 | View |
| Mean Well DLW05B-15 DC-DC Converter - 5W - 18~36V in ±15V out | 5W | 15V | 0.16A | Indoor | $14.95 | View |
| Mean Well DLW05B-12 DC-DC Converter - 5W - 18~36V in ±12V out | 5W | 12V | 0.20A | Indoor | $14.95 | View |
| Mean Well DLW05B-05 DC-DC Converter - 5W - 18~36V in ±5V out | 5W | 5V | 0.5A | Indoor | $14.95 | View |
| Mean Well DLW05A-15 DC-DC Converter - 5W - 9~18V in ±15V out | 5W | 15V | 0.16A | Indoor | $14.95 | View |
| Mean Well DLW05A-12 DC-DC Converter - 5W - 9~18V in ±12V out | 5W | 12V | 0.20A | Indoor | $14.95 | View |
| Mean Well DLW05A-05 DC-DC Converter - 5W - 9~18V in ±5V out | 5W | 5V | 0.5A | Indoor | $14.95 | View |
