Mean Well GST360B24-C6P AC-DC Industrial Adaptor 360W 24V With 6 Pin Connector
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well GST360B24-C6P AC-DC Industrial Adaptor 360W 24V With 6 Pi...
Description
Description
Features
|
Universal AC input / Full range 450W peak power(3 sec.) |
| No load power consumption < 0.5W |
| Energy Efficiency Level VI |
| Meet EISA 2007 (Energy Independence and Security Act) |
| NRCan compliant |
| MEPS compliant |
| 3 pole AC inlet IEC320-C14 |
| Class I power (with earth pin) only |
| Protections: Short circuit /Overload / Over voltage/Over temperature |
| Fully enclosed plastic case |
| LED indicator for power on |
| Built-in active PFC function |
| Fanless design |
| 3 years warranty |
General Specification
| AC input voltage range | 85~264VAC 120~370VDC |
| AC inrush current (max.) | Cold start, 120A at 230VAC |
| Overload protection | 105%~135% rated output voltage, hiccup mode, auto-recovery |
| Over voltage protection | 105%~135% rated output voltage |
| Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: SHORT |
| Working temperature | -30~+70°C (refer to output derating curve ) |
| Safety standards | UL60950-1,CSA C22.2,TUV EN60950-1, BSMI CNS14336, CCC GB4943,PSE J60950-1 approved |
| EMC standards | EN55022 class B, EN61000-3-2,3, FCC part 15 /CISPR22 class B, CNS13438 class B,GB9254,GB17625.1 |
| Length of output cable | 100cm of UL2464, 16AWGx4C |
| Dimension (LxWxH) | 220x 95x 46 mm |
| Standard DC plug |
C6P: MOLEX 6 pin connector |
Specifications
Specifications
-
BrandMean Well
-
SeriesGST Series
-
Power Rating360 Watt
-
Output Voltage36 Volt
-
Rated Current10 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSI,BSMI,CB,CCC,CE,EAC,FCC,KC,PSE,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.66 in
-
Width3.74 in
-
Height1.81 in
-
Weight3.09 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the main output specifications of the GST360B36-C6P?
This Mean Well adaptor provides 36V DC output at up to 10A, for a 360W rated power output. It also supports 450W peak power for 3 seconds. The unit uses a C6P Molex 6 pin connector on the DC output side.
What kinds of equipment is this adaptor typically suited for?
This model is intended for equipment that needs a regulated 36V DC desktop power supply with up to 360W available output. It is generally a fit for industrial and OEM applications where the required voltage, current, and connector style match the product specifications. Buyers should confirm the device requires 36V DC, up to 10A, and a compatible 6 pin Molex interface.
Can this power adaptor be used in demanding industrial environments?
It is designed for industrial use, with an operating temperature range of -30°C to +70°C and a fully enclosed plastic case. The unit is also fanless, which can help reduce dust intake and maintenance concerns in some environments. It includes protection for short circuit, overload, over voltage, and over temperature conditions.
What input power and compliance features does the GST360B36-C6P offer?
This adaptor accepts a universal input range of 85 to 264VAC or 120 to 370VDC and uses an IEC320-C14 AC inlet. It is a Class I power supply with earth pin and includes active PFC. It is rated to Energy Efficiency Level VI and is listed with multiple safety and EMC standards shown in the specification.
How does this model compare with lower-power desktop adaptors?
The GST360B36-C6P is aimed at higher-load applications that need up to 360W continuous output and up to 10A at 36V. Compared with lower-power adaptors, it offers more output headroom and a 450W peak capability for short-duration demand. It is a better choice when the load requirement is beyond the capacity of smaller desktop power supplies.
What should buyers verify for compatibility before ordering this adaptor?
The key compatibility checks are the required DC output rating, connector style, and physical form factor. This unit delivers 36V DC, up to 10A, uses a C6P Molex 6 pin connector, and measures 220 x 95 x 46 mm. It also includes a 100cm output cable and a 3 pole IEC320-C14 AC inlet.
