Mean Well GST360B36-C8P AC-DC Industrial Adaptor 340.5W 15V With 8 Pin Connector
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well GST360B36-C8P AC-DC Industrial Adaptor 340.5W 15V With 8 ...
Description
Description
Features
|
Universal AC input / Full range 450W peak power(3 sec.) |
| No load power consumption < 0.5W |
| Energy Efficiency Level VI |
| Meet EISA 2007 (Energy Independence and Security Act) |
| NRCan compliant |
| MEPS compliant |
| 3 pole AC inlet IEC320-C14 |
| Class I power (with earth pin) only |
| Protections: Short circuit /Overload / Over voltage/Over temperature |
| Fully enclosed plastic case |
| LED indicator for power on |
| Built-in active PFC function |
| Fanless design |
| 3 years warranty |
General Specification
| AC input voltage range | 85~264VAC 120~370VDC |
| AC inrush current (max.) | Cold start, 120A at 230VAC |
| Overload protection | 105%~135% rated output voltage, hiccup mode, auto-recovery |
| Over voltage protection | 105%~135% rated output voltage |
| Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: SHORT |
| Working temperature | -30~+70°C (refer to output derating curve ) |
| Safety standards | UL60950-1,CSA C22.2,TUV EN60950-1, BSMI CNS14336, CCC GB4943,PSE J60950-1 approved |
| EMC standards | EN55022 class B, EN61000-3-2,3, FCC part 15 /CISPR22 class B, CNS13438 class B,GB9254,GB17625.1 |
| Length of output cable | 100cm of UL2464, 16AWGx4C |
| Dimension (LxWxH) | 220x 95x 46 mm |
| Standard DC plug |
C8P: MOLEX 8 pin connector |
Specifications
Specifications
-
BrandMean Well
-
SeriesGST Series
-
Power Rating340.5 Watt
-
Output Voltage15 Volt
-
Rated Current22.7 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSI,BSMI,CB,CCC,CE,EAC,FCC,KC,PSE,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.66 in
-
Width3.74 in
-
Height1.81 in
-
Weight3.09 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the output rating of the GST360B15-C8P power adaptor?
This model provides a regulated 15V DC output with a rated current of 22.7A. Its continuous power rating is 340.5W, with peak power up to 450W for 3 seconds. That makes it suitable for higher-power equipment that requires a 15V desktop-style AC-DC supply.
What types of applications is the GST360B15-C8P typically used for?
The GST360B15-C8P is designed as an industrial AC-DC desktop adaptor for equipment that needs a 15V DC supply at high current. It is generally suited to commercial and industrial devices where a fully enclosed external power supply is preferred. Buyers should confirm the required voltage, current draw, and matching 8 pin connector before selecting it.
Is the GST360B15-C8P compatible with equipment that uses an 8 pin power connector?
This model uses a C8P Molex 8 pin connector on the DC output side. It may be compatible with equipment designed for that connector style, but compatibility depends on the full connector format and the device's required electrical rating. The device must also require 15V DC and stay within the adaptor's 22.7A rated output.
What input voltage range does the GST360B15-C8P support?
The adaptor accepts a universal input range of 85 to 264VAC, and it also supports 120 to 370VDC input. This wide input range makes it practical for use across different mains power regions. It is built with an IEC320-C14 AC inlet and is a Class I unit with earth pin.
Can the GST360B15-C8P be used in demanding temperature conditions?
This model is specified for operation from -30°C to +70°C, subject to the manufacturer's output derating curve. That wide operating range makes it a stronger choice for industrial environments than many general-purpose desktop adaptors. Buyers should still confirm their enclosure and ambient conditions are suitable for the application.
What protection and reliability features does the GST360B15-C8P include?
The GST360B15-C8P includes short circuit, overload, over voltage, and over temperature protection. It also uses hiccup-mode overload protection with auto-recovery. Additional reliability-focused features include a fanless design, active PFC, low no-load power consumption below 0.5W, and a 3-year warranty.
