Mean Well GST360B36-C6P AC-DC Industrial Adaptor 360W 36V With 6 Pin Connector
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well GST360B36-C6P AC-DC Industrial Adaptor 360W 36V With 6 Pi...
Description
Description
Features
|
Universal AC input / Full range 450W peak power(3 sec.) |
| No load power consumption < 0.5W |
| Energy Efficiency Level VI |
| Meet EISA 2007 (Energy Independence and Security Act) |
| NRCan compliant |
| MEPS compliant |
| 3 pole AC inlet IEC320-C14 |
| Class I power (with earth pin) only |
| Protections: Short circuit /Overload / Over voltage/Over temperature |
| Fully enclosed plastic case |
| LED indicator for power on |
| Built-in active PFC function |
| Fanless design |
| 3 years warranty |
General Specification
| AC input voltage range | 85~264VAC 120~370VDC |
| AC inrush current (max.) | Cold start, 120A at 230VAC |
| Overload protection | 105%~135% rated output voltage, hiccup mode, auto-recovery |
| Over voltage protection | 105%~135% rated output voltage |
| Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: SHORT |
| Working temperature | -30~+70°C (refer to output derating curve ) |
| Safety standards | UL60950-1,CSA C22.2,TUV EN60950-1, BSMI CNS14336, CCC GB4943,PSE J60950-1 approved |
| EMC standards | EN55022 class B, EN61000-3-2,3, FCC part 15 /CISPR22 class B, CNS13438 class B,GB9254,GB17625.1 |
| Length of output cable | 100cm of UL2464, 16AWGx4C |
| Dimension (LxWxH) | 220x 95x 46 mm |
| Standard DC plug |
C6P: MOLEX 6 pin connector |
Specifications
Specifications
-
BrandMean Well
-
SeriesGST Series
-
Power Rating360 Watt
-
Output Voltage24 Volt
-
Rated Current15 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSI,BSMI,CB,CCC,CE,EAC,FCC,KC,PSE,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.66 in
-
Width3.74 in
-
Height1.81 in
-
Weight3.09 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the output rating of the Mean Well GST360B24-C6P power adaptor?
This model is rated for 360W output with a 24V DC output and 15A rated current. It is designed as a high-power industrial AC-DC desktop adaptor for equipment that needs a stable 24V supply. The SKU and structured specifications identify this unit as the 24V version.
What type of connector does the GST360B24-C6P use?
The standard DC output plug on this model is a C6P Molex 6-pin connector. It also includes a 100cm output cable specified as UL2464, 16AWGx4C. Buyers should confirm that their equipment matches the required connector format before ordering.
What kinds of applications is this 360W adaptor suited for?
This adaptor is intended for industrial and commercial equipment that requires a high-capacity 24V DC power source. Its 360W continuous rating, 450W peak capability for 3 seconds, and fanless enclosed design make it suitable for demanding B2B applications. It is best matched to devices that need a desktop-style external power supply rather than a board-mount solution.
Can this power adaptor operate in demanding temperature conditions?
Yes, the GST360B24-C6P has a specified working temperature range of -30°C to +70°C, subject to the manufacturer's derating guidance. That makes it more suitable for harsh operating environments than many general-purpose adaptors. Buyers should still verify the full system's temperature requirements, not just the power supply's rating.
What protection features are built into this model?
This model includes protection for short circuit, overload, over voltage, and over temperature. The overload protection is specified as hiccup mode with auto-recovery. These built-in protections help support industrial use where equipment reliability matters.
How energy efficient is the Mean Well GST360B24-C6P?
The adaptor is rated to Energy Efficiency Level VI and has no-load power consumption below 0.5W. It also meets EISA 2007 requirements and is listed as NRCan and MEPS compliant. These characteristics make it a stronger choice where standby power and energy compliance are purchasing considerations.
What input power range does this adaptor support?
The GST360B24-C6P supports a universal AC input range of 85 to 264VAC, and it is also specified for 120 to 370VDC input. This broad range makes it appropriate for international equipment deployments where input conditions can vary. It uses a 3-pole IEC320-C14 AC inlet and is a Class I power supply with earth pin.
What certifications and compliance standards are listed for this model?
This adaptor is listed with multiple safety approvals including UL60950-1, CSA C22.2, TUV EN60950-1, BSMI CNS14336, CCC GB4943, and PSE J60950-1. EMC standards listed include EN55022 Class B, EN61000-3-2 and -3, FCC Part 15/CISPR22 Class B, CNS13438 Class B, GB9254, and GB17625.1. These approvals are relevant for OEMs and industrial buyers who need documented compliance coverage.
