Mean Well HBG-200-48AB Power Supply 200W 48V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HBG-200-48AB Power Supply 200W 48V - Adjustable and Dimmable
The HBG-200 is a 200W Mean Well power converter (input range: 21.6~36V).
Key Features
- ✓ Input voltage range: 21.6~36V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating196.8 Watt
-
Output Voltage48 Volt
-
Rated Current4.1 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.97 in
-
Width5.97 in
-
Height2.62 in
-
Weight3.37 lb
::specification::
Frequently Asked Questions
Can the HBG-200-48AB run a 48V high bay LED light?
Yes, it is rated for constant current operation across 28-48V with 4.1A output and 196.8W maximum power. The HBG series feature list specifically notes high and low bay light use.
Is this driver suitable for 48V illuminated signage in a damp area?
It can be used for 48V signage loads when the total demand stays within 196.8W and the load matches the 28-48V constant current range. Its IP65 water-resistant housing is appropriate for damp or splash-prone areas where full IP67 sealing is not required.
Can I use the HBG-200-48AB for covered outdoor architectural lighting?
Yes, for 48V constant current fixtures that operate within 28-48V and up to 4.1A. The driver is rated for -40°C to +85°C operation and has an IP65 enclosure for water-resistant protection.
What is the maximum 48V LED strip length this driver can handle?
Size the run from the 196.8W maximum output: maximum length = 196.8W divided by the strip watts per meter. Check your strip rated power per meter before final sizing, and keep the load within the 28-48V range.
Is the HBG-200-48AB meant for direct rain and wet outdoor exposure?
This model is IP65 water-resistant, so it is intended for protection against dust and water spray rather than the deeper sealing level associated with IP67. It is also rated for operation from -40°C to +85°C.
How does the HBG-200-48AB compare with the other 200W HBG output voltages?
The 48V models are rated at 196.8W with a 28-48V range and 4.1A output. The 36V versions are 198W with 21-36V and 5.5A, while the 60V versions are 198W with 36-60V and 3.3A.
