Mean Well HBG-200-36AB Power Supply 200W 36V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HBG-200-36AB Power Supply 200W 36V - Adjustable and Dimmable
The HBG-200 is a 200W Mean Well power converter (input range: 21.6~36V).
Key Features
- ✓ Input voltage range: 21.6~36V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating198 Watt
-
Output Voltage36 Volt
-
Rated Current5.5 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.97 in
-
Width5.97 in
-
Height2.62 in
-
Weight3.37 lb
::specification::
Frequently Asked Questions
Can I use the Mean Well HBG-200-36AB for a 36V high bay LED light?
Yes, this model is designed for LED lighting and is specifically noted for high and low bay light use. It provides up to 198W at 36V with 5.5A constant current output, which fits fixtures that need a 36V driver within the 21-36V constant current range.
Is this 36V LED driver suitable for outdoor or damp-location lighting?
It is suitable for environments where an IP65 water-resistant driver is appropriate. The unit is rated IP65 and operates from -40°C to +85°C, so it is built for demanding indoor or outdoor lighting conditions where water resistance is required.
Can I use the HBG-200-36AB for 36V LED strip lighting?
It can work for 36V LED strip lighting if the strip load stays within the driver's 198W maximum output. To estimate strip length, divide 198W by your strip's rated power per meter, and check your strip rated power per meter before sizing.
Can this power supply be used for 36V LED signage or display lighting?
Yes, it can be used for 36V LED signage or display lighting when the load matches a 36V constant current driver and stays within 198W. Its IP65 water-resistant housing and wide 90-305VAC input range also make it a practical option for signage installations exposed to varied operating conditions.
How much 36V LED strip can this driver run?
The maximum available output power is 198W. To estimate the maximum strip length, use 198W divided by your strip's rated power per meter; for example, the formula is 198W ÷ watts per meter, and you should check your strip rated power per meter before final sizing.
What is the difference between the HBG-200-36AB and other HBG-200 series models?
Within the 36V group, HBG-200-36, HBG-200-36A, HBG-200-36AB, HBG-200-36B, and HBG-200-36DA are all listed at 5.5A with a 21-36V constant current range and 198W output. Other HBG-200 variants include the 48V models at 4.1A, 28-48V, and 196.8W, and the 60V models at 3.3A, 36-60V, and 198W.
