Mean Well HBG-200-60 Power Supply 200W 60V
The HBG-200 is a 200W Mean Well power converter (input range: 21.6~36V).
Key Features
- ✓ Input voltage range: 21.6~36V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating198 Watt
-
Output Voltage60 Volt
-
Rated Current3.3 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.97 in
-
Width5.97 in
-
Height2.62 in
-
Weight3.37 lb
::specification::
Frequently Asked Questions
Can I use the HBG-200-60 for a 60V high bay LED fixture?
Yes, if the fixture is designed for constant current operation in the 36-60V range. This driver provides up to 3.3A and 198W, and the series is intended for high and low bay light applications.
Is this driver appropriate for 60V industrial or warehouse lighting?
It is appropriate for 60V-class constant current lighting loads that stay within 36-60V and do not exceed 198W. That makes it suitable for larger industrial lighting assemblies that need more power than the 96W or 156W 60V HBG models.
Can the HBG-200-60 be used for 60V signage or linear lighting?
Yes, for signage or linear lighting systems built around 60V constant current operation. The load must remain inside the 36-60V CC range and under the 3.3A, 198W output limit.
How do I estimate LED strip length for the HBG-200-60?
The driver can supply up to 198W. The math is: maximum strip length = 198W divided by your strip's rated watts per meter, and you should check that the strip is rated for 60V constant current use within the 36-60V range.
Can this driver be used outdoors?
Yes, the HBG-200-60 has an IP67 waterproof rating, so it is suited to outdoor and wet-location lighting systems. Its operating temperature range is -40°C to +85°C.
How does the HBG-200-60 compare with other 60V HBG options?
In the 60V family, HBG-100-60 models are 96W at 1.6A, HBG-160-60 models are 156W at 2.6A, HBG-200-60 is 198W at 3.3A, and HBG-240-60 models are 240W at 4A. All share the 36-60V constant current range, so the key difference is output capacity.
