Mean Well HBG-200-36DA Power Supply 200W 36V - DALI
The HBG-200 is a 200W Mean Well power converter (input range: 21.6~36V).
Key Features
- ✓ Input voltage range: 21.6~36V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating198 Watt
-
Output Voltage36 Volt
-
Rated Current5.5 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.97 in
-
Width5.97 in
-
Height2.62 in
-
Weight3.37 lb
::specification::
Frequently Asked Questions
Can the HBG-200-36DA be used for a 36V high bay or low bay LED fixture?
Yes, this model is intended for constant current LED loads in the 21-36V range with 5.5A output current and 198W maximum power. Its feature list specifically identifies high and low bay light applications.
Is this a good driver for 36V outdoor signage lighting?
It can work for 36V signage lighting if the LED load stays within 198W and the 21-36V constant current range. The IP67 waterproof rating makes it better suited to exposed or damp sign environments than an indoor-only driver.
Can I use the HBG-200-36DA for exterior architectural lighting?
Yes, for 36V constant current fixtures that need up to 5.5A and 198W, this model fits that electrical range. Its IP67 enclosure and -40°C to +85°C operating range support demanding indoor or outdoor conditions.
How much 36V LED strip can this driver support?
Use the power formula based on the 198W maximum: supported length = 198W divided by the strip watts per meter. Check your strip rated power per meter before sizing the run, and make sure the load also fits the 21-36V constant current range.
Is the HBG-200-36DA suitable for wet locations?
Yes, it is rated IP67 waterproof, which is intended for dusty and wet environments. The specified operating temperature range of -40°C to +85°C also supports use in cold and hot conditions.
What are the main differences between the 200W HBG 36V, 48V, and 60V versions?
The 36V versions are rated 198W with a 21-36V output range and 5.5A current. The 48V versions are 196.8W with a 28-48V range and 4.1A, while the 60V versions are 198W with a 36-60V range and 3.3A.
